Car Board 55m/Min 0.7mm PLC Roll Forming Equipment

Name: Car Board 55mMin 07mm PLC Roll Forming Equipment
Brand: LIMING
Price: 1 USD

Brand Name : LIMING

Model Number : LM-Carriage3

Certification : CE、BV、ISO

Place of Origin : Hebei, China

MOQ : 1

Price : Negotiation

Payment Terms : T/T, L/C, D/A, D/P

Supply Ability : 450set/Year

Delivery Time : 40 work days

Packaging Details : Nude、Anti-dust film, Anti-rust cloth

Type : Tile Forming Machine

Production Capacity : 15-55M/Min

Key Selling Points : High-accuracy, High-accuracy

Dimension(L*W*H) : 5000*800*1200Mm

Voltage : 380v 3ph 50hz

thickness : 0.3-0.7mm

Cutting blade material : Cr 12 High Grade Steel

Weight : 3t

Contact Now

Simple operation, new generation car board forming machine

　The purpose of the car compartment plate forming machine is to produce car compartment plates. It is also the primary processed product for cars. It has professional production skills, high assembly efficiency, energy saving and environmental protection, and can produce high-quality products. Therefore, it is deeply loved by people.

The car board forming machine adopts automatic skills to realize automatic tracking, automatic operation, automatic collection and sorting of waste materials, etc., which greatly replaces manual operations. The more green and environmentally friendly, it can help you save a lot of labor costs.

The carriage board products produced by the carriage board forming machine manufacturer have high installation efficiency, long service life and high utilization rate, which can help you quickly open the market and win market competitiveness.

The carriage plate forming machine can be customized for production. Our technical team can design and manufacture a high-precision equipment for you according to the actual model or the product size given by you. At the same time, we will also provide you with a detailed operation tutorial. Help you to operate the car board forming machine proficiently

Technical parameters of Simple operation, new generation car board forming machine

No.	Item	Specification
1	Can Formed Material	PPGI,GI,AI
2	Equipment operation	Automatic
3	Voltage	380V 60Hz 3Phase or as your requirement
4	Thickness of sheet (mm)	0.8-1.6mm
5	Material width(mm)	As your requirement
6	Cover Width of the sheet after formed	As your drawing
7	The size of the roll forming machine	1550016001550mm
8	Speed	8-12m/min
9	Diameter of shaft	85mm
10	Weight of the Machine	11000KGS
11	Material of rollers	45# steel,with hard chrome coated
12	Motor brand	Siemens or Guomao
13	PLC	Siemens or Delta or Mitsubushi
14	Total power (kw)	22kw
15	Power of hydraulic system	11kw
16	Power of main molding core	11kw
